Parking Boom Barrier - Reliable Security for Your Parking Lot Realpark
More Choices
Product Parameter
|
Product Number |
RPH601 |
|
Working Voltage |
24V |
|
The Type of Boom Barrier |
Straight /Folding/Fence Boom |
|
Motor Power |
DC brushless 100w |
|
Operating Temperature |
-40℃ to + 80℃ |
|
Remote Controlling Distance |
≤30m |
|
Remote Controlling Frequency |
430MHz |
|
Chassis Thickness |
1.5mm |
|
Fixed Direction |
Interchangeable left and rights |
|
Brake Rod Length |
straight rod ≤ 4m (DC brushless 1.5~6 seconds) |
|
Brake Pole Length |
Fence pole ≤ 5m (DC brushless 3~6 seconds) |
|
Protection Class |
IP44 |
|
Chassis Size |
1030*340*260mm |
|
The no. of Landing Rod Hits Reached |
5 million times |
The RPH601 Is A High Performance, High Efficiency And Long Service Life Waterproof License Plate Recognition Barrier Gate.
The boom can be rotated 360 degrees to match with the direction of the LCPR equipment. The direction can be interchanged left and right. It has a self-locking system and different color options for matching with other car parking barrier equipment.
Brushless DC movement with adjustable speed
• Auto and manual release parking barrier setting.
• Dry contact for barrier open or close.
• Car detection for avoiding barrier hit car.
• Send signals to change traffic light (when barrier opens)
Tempered glass blue LED backlight, blue light ceiling light, optional traffic light brake lever
• Send signals to change traffic light (when barrier opens)
• Entry station signal output. (after barrier close )
• RPH601 will save close signal when parking barrier is opening.
The remote control opens the gate and enters the convoy mode directly
• System will close parking barrier after complete open process.
• Open signal has higher priority than close signal when parking barrier is closing.
• Car detect signal has higher priority than close signal when parking barrier is closing.
• (Car protect function)
Brushless DC movement with adjustable speed
• System will send alert message if barrier is in wrong position.
• Auto detection of electrical circuit error
• Underground or low ceiling parking lot can use folding barrier.
• Barrier open angles can be option.
Product Parameter
|
Product Number |
RPH601 |
|
Working Voltage |
24V |
|
The Type of Boom Barrier |
Straight /Folding/Fence Boom |
|
Motor Power |
DC brushless 100w |
|
Operating Temperature |
-40℃ to + 80℃ |
|
Remote Controlling Distance |
≤30m |
|
Remote Controlling Frequency |
430MHz |
|
Chassis Thickness |
1.5mm |
|
Fixed Direction |
Interchangeable left and rights |
|
Brake Rod Length |
straight rod ≤ 4m (DC brushless 1.5~6 seconds) |
|
Brake Pole Length |
Fence pole ≤ 5m (DC brushless 3~6 seconds) |
|
Protection Class |
IP44 |
|
Chassis Size |
1030*340*260mm |
|
The no. of Landing Rod Hits Reached |
5 million times |
The RPH601 Is A High Performance, High Efficiency And Long Service Life Waterproof License Plate Recognition Barrier Gate.
The boom can be rotated 360 degrees to match with the direction of the LCPR equipment. The direction can be interchanged left and right. It has a self-locking system and different color options for matching with other car parking barrier equipment.
Brushless DC movement with adjustable speed
• Auto and manual release parking barrier setting.
• Dry contact for barrier open or close.
• Car detection for avoiding barrier hit car.
• Send signals to change traffic light (when barrier opens)
Tempered glass blue LED backlight, blue light ceiling light, optional traffic light brake lever
• Send signals to change traffic light (when barrier opens)
• Entry station signal output. (after barrier close )
• RPH601 will save close signal when parking barrier is opening.
The remote control opens the gate and enters the convoy mode directly
• System will close parking barrier after complete open process.
• Open signal has higher priority than close signal when parking barrier is closing.
• Car detect signal has higher priority than close signal when parking barrier is closing.
• (Car protect function)
Brushless DC movement with adjustable speed
• System will send alert message if barrier is in wrong position.
• Auto detection of electrical circuit error
• Underground or low ceiling parking lot can use folding barrier.
• Barrier open angles can be option.
